Seal Details

Return to Results

Type: 1645S

Click for additional images

Imperial Dimensions

D0

Size Code

D3

L1

Seat Size

0.5	0127	0.937	0.937	127
0.625	0158	1.063	0.937	158
0.75	0191	1.189	0.937	191
0.875	0222	1.315	0.937	222
1	0254	1.437	1	254
1.125	0286	1.563	1	286
1.25	0317	1.689	1	317
1.375	0349	1.941	1.375	349
1.5	0381	1.941	1.125	381
1.625	0412	2.26	1.157	412
1.75	0444	2.315	1.375	444
1.875	0476	2.5	1.375	476
2	0508	2.626	1.375	508
2.125	0539	2.815	1.687	539
2.25	0571	2.846	1.375	571
2.375	0603	3.008	1.687	603
2.5	0635	3.126	1.375	635
2.625	0666	3.252	1.687	666
2.75	0698	3.374	1.687	698
2.875	0730	3.5	1.687	730
3	0762	3.626	1.687	762
3.125	0794	3.752	1.687	0794*
3.250	0826	3.874	1.687	0826*
3.375	0857	4	1.687	0857*
3.500	0889	4.126	1.687	0889*
3.625	0921	4.252	1.687	0921*
3.750	0953	4.374	1.687	0953*
3.875	0984	4.5	1.687	0984*
4.000	1016	4.626	1.687	1016*
