Type: 1659B

Click for additional images

Metric Dimensions

D0

Size Code

D3

L1

Seat Size

18	0180	32	30.5	140
20	0200	34.5	30.5	160
22	0220	36.5	31.5	180
24	0240	38.6	31.5	200
28	0280	43	34.5	240
30	0300	45	34.5	250
33	0330	48.2	37.5	280
35	0350	50	38	300
38	0380	54	38	330
40	0400	56	38	350
43	0430	59	39.5	380
45	0450	61	39.5	400
48	0480	64.2	39.5	430
50	0500	66.3	39.5	450
53	0530	69.7	39.5	480
55	0550	70.8	44	500
58	0580	78	44	530
60	0600	80.1	44	550
63	0630	85.2	49	580
65	0650	85.2	49	600
68	0680	87.8	49	630
70	0700	90	49	650
75	0750	95	55.5	700
80	0800	104.1	55.5	750
85	0850	109.3	55	800
90	0900	114	60	850
95	0950	119.2	60	900
100	1000	124.1	60	950
