Type: 1659S

Click for additional images

Metric Dimensions

D0

Size Code

D3

L1

Seat Size

16	0160	26	23	160
18	0180	32	24	180
20	0200	34.5	24	200
22	0220	36.5	24	220
24	0240	38.6	26.7	240
25	0250	40	27	250
28	0280	43	30	280
30	0300	45	30.5	300
32	0320	47.1	30.5	320
33	0330	48.2	30.5	330
35	0350	50	30.5	350
38	0380	54	32	380
40	0400	56	32	400
43	0430	59	32	430
45	0450	61	32	450
48	0480	64.2	32	480
50	0500	66.3	34	500
53	0530	69.7	34	530
55	0550	70.8	34	550
58	0580	78	39	580
60	0600	80.1	39	600
63	0630	85.2	39	630
65	0650	85.2	39	650
68	0680	87.8	39	680
70	0700	90	45.5	700
75	0750	95	45.5	750
80	0800	104.1	45	800
85	0850	109.3	45	850
90	0900	114	50	900
95	0950	119.2	50	950
100	1000	124.1	50	1000
