Seal Details

Type: 40

40

Click for additional images

Existing Customer? Order on-line

Metric Dimensions

D0Size
Code		D1D3L1L2Seat
Size
18 0180 33 32.5 30 10 180
20 0200 35 34.5 30 10 200
22 0220 37 36.5 30 10 220
24 0240 39 38.5 30 10 240
25 0250 40 39.6 30 10 250
28 0280 43 42.9 32.5 10 280
30 0300 45 44.5 32.5 10 300
32 0320 48 46 32.5 10 320
33 0330 48 47 32.5 10 330
35 0350 50 49.3 32.5 10 350
38 0380 56 52.8 34 11 380
40 0400 58 56 34 11 400
43 0430 61 59 34 11 430
45 0450 63 59 34 11 450
48 0480 66 62.4 34 11 480
50 0500 70 65.6 34.5 13 500
53 0530 73 68.8 34.5 13 530
55 0550 75 70.8 34.5 13 550
58 0580 78 75.2 34.5 13 580
60 0600 80 75.2 34.5 13 600
63 0630 83 78.3 34.5 13 630
65 0650 85 84.2 36 13 650
70 0700 92 87.4 36 15.3 700
73 0730 N/a 90.6 36 N/a 730
75 0750 97 93.7 36 15.3 750

Imperial Dimensions

D0Size
Code		D1D3L1L2Seat
Size
0.75 0191 N/a 33.5 30 N/a 191
0.875 0222 N/a 36.5 30 N/a 222
1 0254 N/a 39.6 30 N/a 254
1.125 0286 N/a 42.9 32.5 N/a 286
1.25 0317 N/a 46 32.5 N/a 317
1.375 0349 N/a 49.3 32.5 N/a 349
1.5 0381 N/a 52.8 34 N/a 381
1.625 0412 N/a 56 34 N/a 412
1.75 0444 N/a 59 34 N/a 444
1.875 0476 N/a 62.4 34 N/a 476
2 0508 N/a 65.6 34.5 N/a 508
2.25 0571 N/a 71.9 34.5 N/a 571
2.375 0603 N/a 75.2 34.5 N/a 603
2.5 0635 N/a 78.3 34.5 N/a 635
2.625 0666 N/a 84.2 36 N/a 666
2.75 0698 N/a 87.4 36 N/a 698
2.875 0730 N/a 90.6 36 N/a 730
3 0762 N/a 93.7 36 N/a 762
