Type: 40L

Click for additional images

Metric Dimensions

D0

Size Code

D1

D3

L1

L2

Slot Width

Slot Depth

Seat Size

18	0180	33	32.5	30	10	4	5.5	180
20	0200	35	34.5	30	10	4	5.5	200
22	0220	37	36.5	30	10	4	5.5	220
24	0240	39	38.5	30	10	4	5.5	240
25	0250	40	39.6	30	10	4	5.5	250
28	0280	43	42.9	32.5	10	4	5.5	280
30	0300	45	44.5	32.5	10	4	5.5	300
32	0320	48	46	32.5	10	4	5.5	320
33	0330	48	47	32.5	10	4	5.5	330
35	0350	50	49.3	32.5	10	4	5.5	350
38	0380	56	52.8	34	11	5	5.5	380
40	0400	58	56	34	11	5	5.5	400
43	0430	61	59	34	11	5	5.5	430
45	0450	63	59	34	11	5	5.5	450
48	0480	66	62.4	34	11	5	5.5	480
50	0500	70	65.6	34.5	13	5	5.5	500
53	0530	73	68.8	34.5	13	5	5.5	530
55	0550	75	70.8	34.5	13	5	5.5	550
58	0580	78	75.2	34.5	13	5	5.5	580
60	0600	80	75.2	34.5	13	5	5.5	600
63	0630	83	78.3	34.5	13	5	5.5	630
65	0650	85	84.2	36	13	5	5.5	650
70	0700	92	87.4	36	15.3	5	5.5	700
73	0730	N/a	90.6	36	N/a	N/a	N/a	730
75	0750	97	93.7	36	15.3	5	5.5	750
