Type: 40S

Click for additional images

Metric Dimensions

D0

Size Code

D1

D3

L1

L2

Seat Size

18	0180	33	32.5	30	10	180
20	0200	35	34.5	30	10	200
22	0220	37	36.5	30	10	220
24	0240	39	38.5	30	10	240
25	0250	40	39.6	30	10	250
28	0280	43	42.9	32.5	10	280
30	0300	45	44.5	32.5	10	300
32	0320	48	46	32.5	10	320
33	0330	48	47	32.5	10	330
35	0350	50	49.3	32.5	10	350
38	0380	56	52.8	34	11	380
40	0400	58	56	34	11	400
43	0430	61	59	34	11	430
45	0450	63	59	34	11	450
48	0480	66	62.4	34	11	480
50	0500	70	65.6	34.5	13	500
53	0530	73	68.8	34.5	13	530
55	0550	75	70.8	34.5	13	550
58	0580	78	75.2	34.5	13	580
60	0600	80	75.2	34.5	13	600
63	0630	83	78.3	34.5	13	630
65	0650	85	84.2	36	13	650
70	0700	92	87.4	36	15.3	700
73	0730	N/a	90.6	36	N/a	730
75	0750	97	93.7	36	15.3	750
